Leaky Bucket Rate Limiting

January 06, 2024

Hmm…leaky bucket? The first time I heard these words, it made me chuckle. I thought what kind of name is this for a rate limiting strategy.

But upon exploring it, it’s rather a very simple, elegant, and popular strategy used in a lot of production environments.

But what are we rate limiting? It’s obvious that we want to rate limit the incoming requests. But do we rate limit the whole server(due to hardware constraints) or do we rate limit per user?

The answer, well, depends on your business requirement. How do you differentiate between different users? As easy way out is we can rate limit based on the IP Address of the request and that’s what we are going to do.

Formal definition:

Leaky Bucket is a method used in network traffic and rate limiting to control the rate of incoming requests and manage potential traffic congestion. It works on a simple analogy of how water flows out of a bucket with a small hole at the bottom.


Here’s how it works:

  1. Bucket as a Buffer: Imagine a bucket that represents a buffer for incoming requests. The size of this bucket determines the buffer capacity, which means how many requests it can hold at any given time.
  2. Constant Requests Outflow: Requests leave the bucket (or buffer) at a constant rate, regardless of the rate at which they arrive. This constant outflow rate ensures that data is processed at a steady, manageable pace per user.
  3. Incoming Requests: Requests arrive at the bucket at varying rates. If the incoming rate is less than or equal to the outflow rate, packets are processed smoothly.
  4. Overflow Management: When the incoming rate exceeds the outflow rate, excess packets start filling the bucket. If the bucket fills up, new incoming packets are discarded and return a 429 - TOO MANY REQUESTS until there is space in the bucket again for the IP address.


The Leaky Bucket algorithm is effective in smoothing out bursty traffic - turning a variable-rate input into a constant-rate output. It’s also useful in ensuring that the data processing doesn’t get overwhelmed during high traffic periods.


It’s widely used in packet-switched networks for congestion control, in APIs for rate limiting requests, and in various other contexts where it’s essential to regulate the flow of data.

Helpful article(s)


The above article is highly recommended because it mentions about some other rate limited strategies like fixed window, sliding window and token bucket rate limiting

The code

Below is a snippet. The whole code can be found at https://github.com/shhivam/ratelimiting4e

type RateLimiter struct {
	RedisDB        *redis.Client
	Duration       time.Duration
	BucketCapacity int64
	ErrorHandler   func(c *gin.Context, err error)
	GetBucketName  func(c *gin.Context) string

func (r RateLimiter) handleIncrement(c *gin.Context, cacheKey string) error {
	value, err := r.RedisDB.Incr(c, cacheKey).Result()
	if value == 1 {
		// Key didn't exist before, so
		// we just created it, and we need to set an expiry
		r.RedisDB.Expire(c, cacheKey, r.Duration)

	return err

func (r RateLimiter) Limit(c *gin.Context) {
	bucketName := r.GetBucketName(c)
	currentBucketSize, err := r.RedisDB.Get(c, bucketName).Result()

	if err != nil && errors.Is(err, redis.Nil) {
		err := r.handleIncrement(c, bucketName)
		if err != nil {
			r.ErrorHandler(c, err)
	} else if err != nil {
		r.ErrorHandler(c, err)

	intValue, err := strconv.ParseInt(currentBucketSize, 10, 64)
	if intValue < r.BucketCapacity {
		r.handleIncrement(c, bucketName)
	} else {
		fmt.Println("got too many requests")
		r.ErrorHandler(c, errors.New("too many requests"))
